Dimensions: 95 x 22 x 1.25 mm
Material: PET/aluminum foil/foam
Operating temperature: -40 to +85°C
Storage temperature: -40 to +120°C
Standard: EPC C1G2 (ISO 18000-6C)
Chip: mPinj Monza R6-P
EPC Memory: 128 (96) bits
User Area Memory: 32 (64) bits
Read Range: US Standard: 10 m on metal surfaces, 12 m on non-metal surfaces; European Standard: 8 m on metal surfaces, 7 m on non-metal surfaces
Data Retention: 10 years
Write Cycles: 100,000
Customization: Logo, barcode/QR code, serial number, data encoding, antenna design, etc.
Applications: Metal container tracking, equipment management, warehouse shelving, automotive parts tracking, IT asset management, etc.
RFID flexible anti-metal tags are electronic tags encapsulated in a special material that technically resolves the challenge faced by standard anti-metal tags, which cannot adhere to irregular or curved metal surfaces. When applied to metal, these anti-metal electronic tags offer excellent read performance and can even be read from a greater distance than when in the air; they are compatible with RFID printers.
Features
● High-quality PET material: Flexible and suitable for bending
Encapsulated in PET material, these tags feature flexibility and water resistance. They are currently widely used in asset management, equipment management, and logistics and warehousing management.
● AutoTune Intelligent Adjustment
The chip utilizes AutoTune technology to automatically and continuously adjust the RF power on the chip, compensating for constantly changing environmental conditions (including the influence of adjacent materials such as fabrics, packaging, and fixtures), thereby significantly improving the responsiveness of the anti-metal tags
● High Performance: Fast, Millisecond-Level Response
The Monza R6 chip’s 32-bit memory encoding requires only 1.6 milliseconds, with an encoding speed exceeding 9,000 tags per minute, easily meeting demands for volume, cost, and order turnaround time.
● Dipole Antenna Significantly Enhances Signal Gain
The folded dipole design improves radiation impedance and antenna efficiency, achieving increased signal gain without expanding the antenna’s footprint.
● Printing Flexibility
LOGOs, barcodes/QR codes, serial numbers, and more can be printed as required. Custom sizes, chip models, and colors are also available. Custom products are non-returnable and non-exchangeable unless there is a quality issue. Please contact online customer service for details.
Application
1. Metal Shelving
2. IT Asset Management
3. Metal Containers, Machinery, and Equipment
